MSU:10G Compact Mobile Screening & Classification System

The MSU:10G is a compact multi-functional solid liquid separation unit.
Yorkshire-Water-MSU10G-670x520-1

The small but mighty solution for maximum dewatering of wet waste.

The MSU:10G is the smallest multipurpose size and density solids separation package in the market. It is designed and configured to be applicable in many waste industries:

  • Tank cleanout operations
  • Gully waste and interceptor cleanouts
  • Drilling muds solids separation
  • Backup and emergency screening

Rapid Deployment

MSU:10G screens are transported by skip or hook lift lorry and integrated into existing fleets. Quick pipework and generator connections allow delivery to deployment in a matter of minutes. Weighing just 5.2 tonnes makes it economical to transport and its retractable cyclone provides easier on-loading and off-loading to trucks.

Return on Investment

MSU:10G recovers up to 90% of material resulting in reduced disposal costs to help your business save money from the start. It can tackle many different jobs and wastes, creating new market opportunities. This highly versatile product can be applied to any mobile solid/liquid separation market including sewage tank sludge, hydro excavation waste and more, allowing for other possible waste processing. MSU:10G features a dual screening system to remove oversize and grit.

TALK TO SALES
THIS IS HOW WE DO IT
EASY TRANSPORT & DEPLOYMENT
Hook-lift truck compatible chassis allows fast and easy transport and deployment. Compact system comes with lifting points to provide quick and easy transportation on a skip lorry.
OPTIMUM FINES RECOVERY
High efficiency hydrocyclone for optimum fines recovery. Cyclone hydraulically retracts and extends for rapid deployment.
COMPLETELY PORTABLE
Control panel enclosure mounted on system ensuring unit is completely portable.
INTEGRATED PUMP
Integrated pump allows for immediate discharge.
PLUG AND PLAY
Self-contained system only requiring a plug and play generator connection.
MSU10G_1

TECHNICAL SPECIFICATION FOR THE MSU:10G

MSU:10G
Maximum Feed Rate15 l/s at 6% DS*
Spraybars Water Requirement (Optional)8 l/s at 4 bar*
Power Requirement27kW
Weight5.2 tonnes
Screening Area1.2m x 2.4m
Transport Dimensions (l x w x h)6.5m x 2.3m x 2.45m

*Dependent on material specification

Zero Limitations

The MSU:10G mobile screen takes screening wherever it needs to be quickly and easily.

It’s smaller than other mobile products on the market so if site size is a problem this compact system is the answer. Its simple, compact design means it can adjust to site space limitations while also reducing health and safety risks for operators, helping to reduce the overall operational costs of your business.
